Tasks

A task is child to a project and contains the details of the job to be run. A typical task will run a sql query, format the results and upload them as a file into a SFTP server.

Tasks include three primary pages:

∞ Task Details

From the task details a task can be

Following this most task details are listed along with a log, and a listing of historical file outputs.

The history files can be downloaded or resent to the current destination.

∞ New Task

There are many options for creating new tasks!

∞ Parameters

See the parameters page for more parameter options.

∞ Retries

If a task has a non-catastrophic failure, meaning that the app is still running and the error has been logged, we have the option to attempt multiple retries. This is especially useful when uploading files into SFTP’s where you cannot control the upload speeds etc, and may be subject to upload errors.

In cases like this it is advisable to allow the task to rerun.

∞ Run Rank

Run Rank determines which order the tasks will be run in, only if the project is set to run tasks in series.

∞ Data Sources

Most of the data source/ destination options are fairly consistent through all the option groups.

Data sources must first be created in the connections page.

∞ Database

A source organization and database can be selected.

The option “Include Query Headers” will include/exclude column headings from the output.

A query location must be chosen. The query can be loaded from SFTP, FTP, SMB, Gitlab, web url (for example, github + access token), or can be entered directly as “source code”.

SQL queries will do a row count as the queries run and will log the current row count to the task log.

There is an option to save queries from Gitlab and web urls when the app runs, and if there is ever a connection issue pulling the code, the cached version will be used. The sql is cached before parameters are inserted so parameters will continue to work.

∞ FTP/SFTP/SMB

These data source options allow a remote file to be loaded and sent to a destination. This is a nice option if a file must be reformatted.

For example a csv can be loaded and changed to a pipe delimited file.

∞ Python Script

While a python script can be run as an add-on to any data source (through Processing Script), if you only wish to run a python script and not have any other data source you can choose this option.

∞ SSH

If you only need to schedule a command to run on a remote server this is the option to use.

It will attempt to connect to a remote server through SSH and run whatever command you specify.

The commands can be loaded from an external script (through SFTP, FTP, SMB, Gitlab or web url), or internally through the code editor.

∞ Processing Script

Data from the source is passed into a local file and can be modified with a python script. Also, if you choose Python Script you can run a python script without input.

Python scripts have access to task and project metadata, including parameters and any connection strings used. They are passed in through environment variables. Access them through os.environ:

import os
print(os.environ)

If there is a data source selected it will be passed into your python script as an argument.

Source files names can be picked up like this:

import sys
input_file = sys.argv[1]

All processing scripts are run in their own environment and dependencies are automatically installed as needed.

The Processing Script can be loaded from a multitude of places. You can load a multi file package and choose what file to run as well.

A processing script can also return a new file name, or file names. The format must be a list of full paths as strings. Here’s an example script that splits the output from a sql job into multiple files.

Assume a sql query of:

select 1
union all
select 2

It will produce an output with two rows.

Assume a python script of:

import sys
import csv
from pathlib import Path

outPaths = []
input_file = sys.argv[1]

# this is where any new files should be placed
baseDir = Path(input_file).parent

# ...do something here with input...
# example write something into several files
with open(Path(input_file), 'r') as source:
  r = csv.reader(source)

  for x, row in enumerate(r):
    currentFile = Path(baseDir / f'test-{x}.txt')
    outPaths.append(str(currentFile))

    with open(currentFile, 'w') as fp:
      fp.write(str(row))

# print the new paths back
print(outPaths)

This will produce two files (test-0.txt and test-2.txt). These files are what would be backed up or sent to a vendor. They would also be available for download on the file page.

∞ Data Destination

Once data is gather is can be sent out!

First set the output file type and name. The file name can use python type data parameters. See the parameters page for more parameter options.

Leave the type and name blank if you are moving files and want to keep the original names.

If needed, the file can be sent inside a zip folder.

Additional characters can be appended to each line in the file.

∞ File Encryption

Files can be encrypted using a gpg key. Check the box to run encryption on and pick the encryption key from the dropdown.

Filenames will be preserved and “.gpg” appended to the current extension. Files will be encrypted before zipping if the zip option is selected.

∞ md5 Hash

After creating the file, and optionally encrypting the file, a md5 hash of the file is created and save along with the file name, file size, etc, for future file verification.

∞ SFTP/SMB/FTP

The output file can be loaded into an existing connection.

There is an option to attempt to replace existing files with the same name, however this option is also set on the SFTP server level and may conflict.

Also, you can prevent an empty file (for sql, an output with 0 rows, excluding headers) from uploading by checking the box to disable empty uploads. This will also prevent an empty file from being zip’d and sent.

∞ Email

Getting a success/failure email from the extract can be useful. You have the option to attach or embed the output file to the email as well. Use with caution if you are querying sensitive data, or have a file that may exceed or email size limit.

It is also possible to send a text message. Phone numbers can be entered as an email address using the email to sms gateway. You can find the gateway address for your provider here.

If you have phone numbers in the address list they will get a plain text message sent by sms, containing only the success or error message you’ve configured in the app. If no message is entered the default message will send.

∞ Enable Task

There is an option to enable the task immediately. If this is checked then the task will be picked up an run next time the project is triggered by the Scheduler API.
